ZBasic System Library
19
ZBasic Microcontrollers
8-bit PWM Timers, Channels and Pins for Generic Target Devices
Target Devices
Pkg.
Timer
Chan.
Pin
Chan.
Pin
tiny48, tiny88
all
-
tiny24, tiny24A, tiny44, tiny44A, tiny84, tiny84A
P14
Timer0
1
5, B.2
2
6, A.7
Q20
1
14, B.2
2
15, A.7
tiny87, tiny167
S20
Timer0
1
3, A.2
T32
1
31, A.2
tiny2313, tiny2313A, tiny4313
P20
Timer0
1
14, B.2
2
9, D.5
Q20
1
7, B.2
2
12, D.5
tiny828¹
T32
Timer0
1
31, C.0
2
32, C.1
tiny441, tiny841¹
S14
Timer0
1
7, A.6
2
8, A.5
Q20
1
16, A.6
2
20, A.5
tiny1634
S20
Timer0
1
17, C.0
2
4, A.5
Q20
1
15, C.0
2
2, A.5
mega8, mega8A
P28
Timer2
1
17, B.3
T28
1
13, B.3
T32
1
15, B.3
mega48, mega48A, mega48P, mega48PA, mega48PB, mega88,
mega88A, mega88P, mega88PA, mega88PB, mega168,
mega168A, mega168P, mega168PA, mega168PB, mega328,
mega328P, mega328PB
P28
Timer2
1
17, B.3
2
5, D.3
T28
1
13, B.3
2
1, D.3
T32
1
15, B.3
2
1, D.3
mega16, mega16A, mega32, mega32A
P40
Timer2
1
21, D.7
T44
1
16, D.7
mega644, mega644A, mega164A, mega164P, mega164PA,
mega324P, mega324PA, mega644P, mega644PA, mega1284P
P40
Timer2
1
21, D.7
2
20, D.6
T44
1
16, D.7
2
15, D.6
mega64, mega64A, mega128, mega128A, AT90CAN32,
AT90CAN64, AT90CAN128
T64
Timer0
1
17, B.7
mega1281, mega2561
T64
Timer0
1
17, B.7
2
1, G.5
AT90USB646, AT90USB647, AT90USB1286, AT90USB1287
T64
Timer0
1
17, B.7
2
25, D.0
mega640, mega1280, mega2560
T100
Timer0
1
26, B.7
2
1, G.5
mega8U2, mega16U2, mega32U2, AT90USB82, AT90USB162
T32
Timer0
1
21, B.7
6
6, B.0
mega16U4, mega32U4
T44
Timer4
1
3
32, C.7
27, D.7
2
30, B.6
mega8515
P40
Timer0
1
1, B.0
T44
1
40, B.0
L44
1
2, B.0
mega8535
P40
Timer2
1
21, D.7
T44
1
16, D.7
L44
1
22, D.7
mega161, mega162
P40
Timer2
1
2, B.1
T44
1
41, B.1
mega163, mega323
P40
Timer2
1
21, D.7
T44
1
16, D.7
mega165, mega165A, mega165P, mega165PA, mega325,
mega325P, mega645, mega645A, mega645P, mega169,
mega169A, mega169P, mega169PA, mega329, mega329P,
mega329PA, mega649, mega649A, mega649P
T64
Timer2
1
17, B.7
mega3250, mega3250P, mega6450, mega6450A, mega6450P,
mega3290, mega3290P, mega6490, mega6490A, mega6490P
T100
Timer2
1
26, B.7
all xmega
all
-
1
These devices support mapping of timer output compare pins; the pins listed are the default pins.
 |
 |
 |
