ZBasic System Library
18
ZBasic Microcontrollers
TimerF1
19
49, F.4
20
50, F.5
xmegaA3, xmegaA3B,
xmegaA3U, xmegaA3BU
T64
TimerD0
TimerD1
TimerC0
TimerE0
TimerE1
TimerF0
1
3
5
7
9
11
13
15
17
26, D.0
30, D.4
16, C.0
18, C.2
36, E.0
38, E.2
40, E.4
46, F.0
48, F.2
2
4
6
8
10
12
14
16
18
27, D.1
31, D.5
17, C.1
19, C.3
37, E.1
39, E.3
42, E.5
47, F.1
49, F.3
xmegaA4, xmegaA4U
T44
TimerD0
TimerD1
TimerC0
TimerE0
1
3
5
7
9
11
20, D.0
24, D.4
10, C.0
12, C.2
28, E.0
32, E.2
2
4
6
8
10
12
21, D.1
25, D.5
11, C.1
13, C.3
29, E.1
33, E.3
xmegaD3
T64
TimerD0
TimerC0
TimerE0
TimerF0
1
3
5
7
9
11
13
26, D.0
16, C.0
18, C.2
36, E.0
38, E.2
46, F.0
48, F.2
2
4
6
8
10
12
14
27, D.1
17, C.1
19, C.3
37, E.1
39, E.3
47, F.1
49, F.3
xmegaD4
T44
TimerD0
TimerC0
TimerE0
1
3
5
7
9
20, D.0
10, C.0
12, C.2
28, E.0
32, E.2
2
4
6
8
10
21, D.1
11, C.1
13, C.3
29, E.1
33, E.3
1
These devices support mapping of timer output compare pins; the pins listed are the default pins.
The tables below give the set of valid 8-bit PWM channels, the associated timer, and the corresponding
output pin for each channel. See OpenPWM8 for the details of setting up an 8-bit PWM output.
8-bit PWM Timers, Channels and Pins for ZX Devices
ZX Device
Timer
Chan.
Pin
Chan.
Pin
ZX-24
Timer2
1
25, D.7
-
ZX-40
Timer2
1
21, D.7
-
ZX-44
Timer2
1
16, D.7
-
ZX-24a, ZX-24p, ZX-24n, ZX-24r, ZX-24s, ZX-24t
Timer2
1
25, D.7
2
12, D.6
ZX-40a, ZX-40p, ZX-40n, ZX-40r, ZX-40s, ZX-40t
Timer2
1
21, D.7
2
20, D.6
ZX-44a, ZX-44p, ZX-44n, ZX-44r, ZX-44s, ZX-44t
Timer2
1
16, D.7
2
15, D.6
ZX-328n, ZX-328l
Timer2
1
17, B.3
2
5, D.3
ZX-32n, ZX-32l
Timer2
1
15, B.3
2
1, D.3
ZX-1281, ZX-1281n
Timer0
1
17, B.7
2
1, G.5
ZX-1280, ZX-1280n
Timer0
1
26, B.7
2
1, G.5
ZX-24e
Timer2
1
13, D.7
-
ZX-24ae, ZX-24ne, ZX-24pe,
ZX-24nu, ZX-24pu, ZX-24ru, ZX-24su
Timer2
1
13, D.7
2
14, D.6
ZX-128e, ZX-128ne
Timer2
1
17, B.7
-
ZX-1281e, ZX-1281ne
Timer0
1
21, B.7
2
G.5
ZX-328nu
Timer2
1
14, B.3
2
6, D.3
 |
 |
 |
