PutPin(pin, mode)
Parameter
Method
Type
Description
pin
ByVal
Byte
The pin to configure.
mode
ByVal
Byte
The configuration mode (see below).
Discussion
This routine is used to configure a pin to be an input or an output or to effect a change in the output logic
level. If the pin is configured as an input, it may be configured to be in “tri-state” mode or “pull-up” mode.
If the pin is configured to be an output, the output level may be set to zero or 1. The table below gives the
values for each of the possible modes. If an invalid mode is specified or an invalid pin is specified, the
routine has no effect.
Values for the mode Parameter
Value
Built-in Constant
Description
0
zxOutputLow
The pin is an output at logic zero.
1
zxOutputHigh
The pin is an output at logic one.
2
zxInputTriState
The pin is an input with the pull-up/pull-down resistors disabled.
3
zxInputPullUp
The pin is an input with the pull-up resistor enabled.
4
zxOutputToggle
Change the logic level of the output.
5
zxOutputPulse
Pulse the output.
6
zxInputPullDown
The pin is an input with the pull-down resistor enabled.
7
zxInvertIO
Input and output levels are inverted.
8
zxNormalIO
Input and output levels are normal (non-inverted).
Note that for modes 4 and 5 to be useful, the pin must have been previously set to be an output. Mode 4
(zxOutputToggle) will change the output to the opposite logic level. Mode 5 (zxOutputPulse) will
change the output to the opposite level for a short period of time and then change it back to the original
level. The duration of the pulse will be about 8 CPU cycles (approximately 0.5uS at 14.7456MHz).
Modes 6, 7 and 8 are only supported on xmega targets. Modes 7 and 8 are to be used in conjunction
with the other modes (in separate calls, of course) to achieve the desired configuration.
Example
Call PutPin(12, zxOutputLow)
' pin 12 will be at logic zero
Compatibility
In BasicX compatibility mode, mode values higher than 3 are not supported.
