ZBasic System Library
245
ZBasic Microcontrollers
Type
Subroutine
Invocation
PutPersistent(addr, var, count)
Parameter
Method
Type
Description
addr
ByVal
int16
The Persistent Memory address to which to write.
var
ByRef
any type
The variable from which data will be taken.
count
ByVal
int8/16
The number of bytes to write.
Discussion
This routine reads one or more bytes from RAM and writes them to Persistent Memory beginning at the
address given.
Caution
Persistent Memory has a write cycle limit of approximately a million writes. Writing to a particular address
in excess of this limit may cause the memory to become unreliable.
A block of Persistent Memory starting at address zero is reserved for system use. When the compiler
assigns addresses to persistent variables defined in your program, the lowest address used is the first
address above this reserved block. The .map file generated by the compiler contains a section indicating
the addresses assigned to persistent variables defined in your program. The built-in values
Register.PersistentStart, Register.PersistentSize and Register.PersistentUsed
may be useful for determining the allocated an unallocated portions of Persistent Memory.
This routine will write to any address in Persistent Memory. Generally, you should avoid writing to the
reserved area of Persistent Memory.
Example
Dim pvar(1 to 10) as PersistentByte
Dim var(1 to 10) as Byte
Call PutPersistent(pvar.DataAddress, var, SizeOf(pvar))
Compatibility
This routine is not available in BasicX compatibility mode.
