OpenI2C
Type
Subroutine
Invocation
OpenI2C(channel, sdaPin, sclPin) or
OpenI2C(channel, sdaPin, sclPin, bitRate)
Parameter
Method
Type
Description
channel
ByVal
Byte
The I2C channel to open (0-4).
sdaPin
ByVal
Byte
The pin for the I2C data (SDA) signal.
sclPin
ByVal
Byte
The pin for the I2C clock (SCL) signal.
bitRate
ByVal
integral
The optional clock speed designation, see discussion.
Discussion
This subroutine prepares an I2C channel for use.  Five channels are supported, numbered 0 through 4.
Channel zero uses the onboard hardware I2C controller (if available) while channels 1 through 4 are
generally implemented in software.  However, on devices with multiple I2C controllers (e.g. xmega-based
devices) channels 1 to 4 can be used for the additional hardware I2C controllers by specifying the SCL
and SDA pins as zero.  The I2C implementation does not support multi-master arbitration when operating
in Master mode.  Slave clock stretching is supported on both hardware and software channels.
For channel 0, the sdaPin and sclPin parameters are ignored since the hardware uses specific pins for
the SDA and SCL signals (e.g. Port C, bits 1 and 0, respectively).  For channels 1-4 in software mode, the
sdaPin and sclPin parameters specify the pins to use for the data and clock signals, respectively.  In
both cases, the clock and data pins are automatically configured for I2C operation.  The I2C protocol
requires pullup resistors on both of the lines, the value of which depends on characteristics of your
system.  A typical value is in the range of 1.5K to 4.7K.
The optional bitRate parameter allows you to control the speed of the data interchange.  If the
parameter is not given, the default speed is 100KHz.  Each I2C device has a maximum clock rate at
which it will operate reliably; check the datasheet of your selected device to determine the maximum rate.
The interpretation of the value of the bitRate parameter differs for channel 0 and channels 1-4.  The
tables below specify the values to use for several common clock speeds.
I2C Hardware Channel Clock Speeds
bitRate
Value
Approximate
Clock Speed
Notes
140
50KHz
66
100KHz
Standard Low Speed, default speed
29
200KHz
11
388KHz
Closest to Standard High Speed (400KHz)
10
410KHz
Highest supported speed
I2C Software Channel Clock Speeds¹
bitRate
Value
Approximate
Clock Speed
Notes
295
50KHz
148
100KHz
Standard Low Speed, default speed
74
200KHz
59
250KHz
Highest supported speed
1
The values given assume the default setting of Register.TimerSpeed1.
For hardware channels, the bitRate parameter controls the hardware bit rate.  For ATmega-based
devices, the parameter is a composite of two values: the value in the lower 8 bits is known as BR and is
