ZBasic System Library

ZBasic Microcontrollers

Function returning UnsignedInteger

CRC16(data, count, crcPoly, crcInit, crcFlags)

The data bytes to add to the CRC value.

The number of bytes to process.

UnsignedInteger

The CRC polynomial to use.

UnsignedInteger

The initial value of the CRC.

Flag bits that control the CRC computation.

This function computes the CRC value over a number of data bytes using a specified polynomial and

initial value. The values to use for the polynomial and the initial value depend on the style of CRC that

you need to generate. See the discussion below for further details. The flags parameter contains bits

that control aspects of the CRC computation as described in the table below.

Flag Values for the CRC Compuation

Each input data bytes will be “reflected”.

The final CRC value will be “reflected”.

The remaining bits are reserved for future use and should always be zero.

In this context, the term “reflection” refers to reversing the order of the bits in a data item so that the most

significant becomes the least significant and vice versa. For a multi-byte data item, the bits in each byte

are reversed and the order of the bytes is reversed as well.

Although this function will typically be used to compute the CRC value for an entire block of data at once,

it may also be used in a byte-by-byte or data burst mode. To do so, you would pass the computed CRC

value from the previous iteration as the initial value. Note, however, that you shouldn’t use the zxRefOut

flag bit in this case. Rather, if you need reflected output you would perform the bit reversal on the final

CRC value when you reach the end of the data stream. You can reverse the bit order of a 16-bit value by

using the following code fragment.

crc = MakeWord(FlipBits(HiByte(crc)), FlipBits(LoByte(crc)))

CRC algorithms can be described by a parametric model known as the RockSoft model (see

http://www.repairfaq.org/filipg/LINK/F_crc_v34.html#CRCV_005). This CRC implementation supports the

POLY, INIT, REFIN and REFOUT parameters of the model with WIDTH=16 and XOROUT=0. If

necessary, you can easily implement a non-zero XOROUT parameter by using the following code

crc = crc Xor XorOutValue

The Rocksoft model parameters for commonly used CRC computations are given in the table below.
