ZBasic System Library
29
ZBasic Microcontrollers
18, 19
tiny828
T32
1-3, 6-17, 19, 20,
22-32
tiny1634
S20
1-6, 15-20
Q20
1-4, 13-18
mega48, mega48A, mega48P, mega48PA, mega48PB, mega88, mega88A,
mega88P, mega88PA, mega88PB, mega168, mega168A, mega168P,
mega168PA, mega168PB, mega328, mega328P, mega328PB
P28
23-28
T28
19-24
T32
23-28, 19, 22
mega16, mega16A, mega164A, mega164P, mega164PA, mega32,
mega32A, mega324P, mega324PA, mega644, mega644A, mega644P,
mega644PA, mega1284P
P40
33-40
T44
40-47
mega64, mega64A, mega128, mega128A, mega1281, mega2561,
AT90CAN32, AT90CAN64, AT90CAN128
T64
54-61
mega640, mega1280, mega2560
T100
82-89, 90-97
mega16U4, mega32U4
T44
36-41
mega8535, mega163, mega323
P40
33-40
T44
30-37
L44
36-43
mega165, mega165A, mega165P, mega165PA, mega325, mega325P,
mega645, mega645A, mega645P, mega169, mega169A, mega169P,
mega169PA, mega329, mega329P, mega329PA, mega649, mega649A,
mega649P
T64
54-61
mega3250, mega3250P, mega6450, mega6450A, mega6450P, mega3290,
mega3290P, mega6490, mega6490A, mega6490P
T100
90-97
AT90USB646, AT90USB647, AT90USB1286, AT90USB1287
T64
54-61
xmegaA1, xmegaA1U
T100
95-100, 1-2, 5-12
xmegaA3, xmegaA3U, xmegaA3B, xmegaA3BU
T64
62-64, 1-5, 6-13
xmegaA4, xmegaA4U
T44
40-44, 1-3, 4-7
xmegaD3
T64
62-64, 1-5
xmegaD4
T44
40-44, 1-3
The table below indicates the available channels and the corresponding DAC hardware used.
Supported DAC Channels for ZX Devices
ZX Devices
DACB
DACA
ZX-24x, ZX-24u
Chan 1, Pin 8
Chan 2, Pin 9
-
ZX-32a4
Chan 1, Pin 6 (B.2)
Chan 2, Pin 7 (B.3)
-
ZX-128a1
Chan 1, Pin 7 (B.2)
Chan 2, Pin 8 (B.3)
Chan 3, Pin 97 (A.2)
Chan 4, Pin 98 (A.3)
ZX-24xu
Chan 1, Pin 26 (B.2)
Chan 2, Pin 25 (B.3)
-
Supported DAC Channels for Generic Target Devices
ZX Devices
DACB
DACA
xmegaA1, xmegaA1U
Chan 1, Pin 7 (B.2)
Chan 2, Pin 8 (B.3)
Chan 3, Pin 97 (A.2)
Chan 4, Pin 98 (A.3)
xmegaA3, xmegaA3B,
xmegaA3U, xmegaA3BU
Chan 1, Pin 7 (B.2)
Chan 2, Pin 8 (B.3)
-
xmegaA4, xmegaA4U
Chan 1, Pin 6 (B.2)
-
 |
 |
 |
