ZBasic System Library
23
ZBasic Microcontrollers
TimerE0
17, E.1
ZX-32a4
TimerC0
TimerE0
11, C.1
29, E.1
TimerD0
21, D.1*
ZX-128a1
TimerC0
TimerE0
TimerF0
16, C.1
36, E.1
46, F.1
TimerD0
TimerE1
TimerF1
26, D.1*
40, E.5
50, F.5
ZX-24e, ZX-24ae, ZX-24ne, ZX-24pe, ZX-24nu, ZX-24pu
Timer1
13, D.4*
ZX-24ru, ZX-24su
Timer1
16, D.4*
Timer3
21, B.7
ZX-128e, ZX-128ne, ZX-1281e, ZX-1281ne
Timer1
Timer3
22, B.6*
16, E.4
Timer1
21, B.7¹
ZX-328nu
Timer1
13, B.2*
ZX-24xu
TimerC0
TimerE0
11, C.1
23, E.1
TimerD0
13, D.1*
*
Denotes the default OutputCapture pin.
1
Requires the TIMER1_COMPC ISR and supports OutputCapture modulation.
Hardware Output Capture Pins for Generic Target Devices
Target Device
Pkg.
Timer
Output
Pin
tiny24, tiny24A, tiny44, tiny44A, tiny84, tiny84A
P14
Timer1
8, A.5*
Q20
Timer1
20, A.5*
tiny48, tiny88
P28
Timer1
16, B.2*
T28
Timer1
12, B.2*
T32
Timer1
14, B.2*
tiny441, tiny841²
S14
Timer1
Timer2
6, A.7*
10, A.3
Q20
Timer1
Timer2
15, A.7*
2, A.3
tiny87, tiny167
S20
Timer1
19, B.1*
T32
Timer1
27, B.1*
tiny2313, tiny2313A, tiny4313
P20
Timer1
16, B.4*
Q20
Timer1
14, B.4*
tiny828²
T32
Timer1
8, C.7*
tiny1634
S20
Timer1
3, A.6*
Q20
Timer1
1, A.6*
mega48, mega48A, mega48P, mega48PA, mega48PB, mega88, mega88A,
mega88P, mega88PA, mega88PB, mega168, mega168A, mega168P,
mega168PA, mega168PB, mega328, mega328P, mega328PB
P28
Timer1
16, B.2*
T28
Timer1
12, B.2*
T32
Timer1
14, B.2*
(mega328PB only)
T32
Timer3
32, D.2
(mega328PB only)
T32
Timer4
32, D.2
mega16, mega16A, mega32, mega32A, mega644, mega644A, mega164A,
mega164P, mega164PA, mega324P, mega324PA, mega644P, mega644PA
P40
Timer1
18, D.4*
T44
Timer1
13, D.4*
mega1284P
P40
Timer1
Timer3
18, D.4*
8, B.7
T44
Timer1
Timer3
13, D.4*
3, B.7
mega64, mega64A, mega128, mega128A, mega1281, mega2561,
AT90CAN32, AT90CAN64, AT90CAN128
T64
Timer1
Timer1
Timer3
16, B.6*
17, B.7¹
6, E.4
AT90USB646, AT90USB647, AT90USB1286, AT90USB1287
T64
Timer1
Timer1
Timer3
16, B.6*
17, B.7¹
40, C.5
mega640, mega1280, mega2560
T100
Timer1
Timer1
Timer3
25, B.6*
26, B.7¹
6, E.4
 |
 |
 |
