Valid Input Capture Pins for Generic Target Devices
Underlying CPU Type
Pkg.
Timer
Pin
tiny24, tiny24A, tiny44, tiny44A, tiny84, tiny84A
P14
Timer1
6, A.7*
Q20
Timer1
15, A.7*
tiny48, tiny88
P28
Timer1
14, B.0*
T28
Timer1
10, B.0*
T32
Timer1
12, B.0*
tiny441, tiny841
S14
Timer1
Timer2
6, A.7*
5, B.2
Q20
Timer1
Timer2
15, A.7*
14, B.2
tiny87, tiny167
S20
Timer1
7, A.4*
T32
Timer1
9, A.4*
tiny2313, tiny2313A, tiny4313
P20
Timer1
11, D.6*
Q20
Timer1
9, D.6*
tiny828
T32
Timer1
6, C.5*
tiny1634
S20
Timer1
16, C.1*
Q20
Timer1
14, C.1*
mega48, mega48A, mega48P, mega48PA, mega48PB, mega88,
mega88A, mega88P, mega88PA, mega88PB, mega168,
mega168A, mega168P, mega168PA, mega168PB, mega328,
mega328P, mega328PB
P28
Timer1
14, B.0*
T32
Timer1
12, B.0*
(mega328PB only)
T32
Timer3
19, E.2
(mega328PB only)
T32
Timer4
3, E.0*
mega16, mega16A, mega164A, mega164P, mega164PA, mega32,
mega32A, mega324P, mega324PA, mega644, mega644A,
mega644P, mega644PA
P40
Timer1
20, D.6*
T44
Timer1
15, D.6*
mega1284P
P40
Timer1
Timer3
20, D.6*
6, B.5
T44
Timer1
Timer3
15, D.6*
1, B.5
mega8515
P40
Timer1
31*
T44
Timer1
21*
L44
Timer1
35*
mega8535, mega163, mega323
P40
Timer1
20, D.6*
T44
Timer1
15, D.6*
L44
Timer1
21, D.6*
mega161, mega162
P40
Timer1
31, E.0*
T44
Timer1
29, E.0*
mega165, mega165A, mega165P, mega165PA, mega325,
mega325P, mega645, mega645A, mega645P,
mega169, mega169A, mega169P, mega169PA, mega329,
mega329P, mega329PA, mega649, mega649A, mega649P
T64
Timer1
25, D.0*
mega3250, mega3250P, mega6450, mega6450A, mega6450P,
mega3290, mega3290P, mega6490, mega6490A, mega6490P
T100
Timer1
43, D.0*
mega1281, mega2561, mega64, mega64A, mega128, mega128A
AT90CAN32, AT90CAN64, AT90CAN128, AT90USB646,
AT90USB647, AT90USB1286, AT90USB1287
T64
Timer1
Timer3
29, D.4*
9, E.7
mega640, mega1280, mega2560
T100
Timer1
Timer3
Timer4
Timer5
47, D.4*
9, E.7
35, L.0
36, L.1
mega8U2, mega16U2, mega32U2, AT90USB82, AT90USB162
T32
Timer1
22, C.7*
mega16U4, mega32U4
T44
Timer1
Timer3
25, D.4*
32, C.7
xmegaA1, xmegaA1U
T100
TimerC0
15, C.0*
 |
 |
 |
