ZBasic System Library
310
ZBasic Microcontrollers
Type
Function returning Byte
Invocation
StatusTask(taskStack)
StatusTask()
Parameter
Method
Type
Description
taskStack
ByRef
array of Byte
The stack for a task of interest.
Discussion
This function returns a value indicating the status of the task associated with the given task stack. If no
task stack is explicitly given, the task stack for the Main() routine is assumed. The return values and
their respective meanings are shown in the table below.
Task Status Values
Constant
Value
Meaning
TaskReady
0
The task is running or ready to run.
TaskSleeping
1
The task is sleeping.
TaskWaitInputCapture
2
The task is waiting for InputCapture() to complete.
TaskWaitInt0
3
The task is awaiting Interrupt 0.
TaskWaitInt1
4
The task is awaiting Interrupt 1.
TaskWaitInt2
5
The task is awaiting Interrupt 2.
TaskWaitInterval
6
The task is waiting for the interval counter to expire.
TaskWaitAnalogCompare
7
The task is waiting for an analog comparator event.
TaskWaitPinChange0
8
The task is waiting for a pin change event 0.
TaskWaitPinChange1
9
The task is waiting for a pin change event 1.
TaskWaitPinChange2
10
The task is waiting for a pin change event 2.
TaskWaitPinChange3
11
The task is waiting for a pin change event 3.
TaskWaitOutputCapture
12
The task is waiting for OutputCapture() to complete.
TaskWaitInt3
13
The task is awaiting Interrupt 3.
TaskWaitInt4
14
The task is awaiting Interrupt 4.
TaskWaitInt5
15
The task is awaiting Interrupt 5.
TaskWaitInt6
16
The task is awaiting Interrupt 6.
TaskWaitInt7
17
The task is awaiting Interrupt 7.
TaskWaitPinChangeA0
18
The task is waiting for a pin change event, port A.
TaskWaitPinChangeA1
19
The task is waiting for a pin change event, port A.
TaskWaitPinChangeB0
20
The task is waiting for a pin change event, port B.
TaskWaitPinChangeB1
21
The task is waiting for a pin change event, port B.
TaskWaitPinChangeC0
22
The task is waiting for a pin change event, port C.
TaskWaitPinChangeC1
23
The task is waiting for a pin change event, port C.
TaskWaitPinChangeD0
24
The task is waiting for a pin change event, port D.
TaskWaitPinChangeD1
25
The task is waiting for a pin change event, port D.
TaskWaitPinChangeE0
26
The task is waiting for a pin change event, port E.
TaskWaitPinChangeE1
27
The task is waiting for a pin change event, port E.
TaskWaitPinChangeF0
28
The task is waiting for a pin change event, port F.
TaskWaitPinChangeF1
29
The task is waiting for a pin change event, port F.
TaskWaitPinChangeH0
30
The task is waiting for a pin change event, port H.
TaskWaitPinChangeH1
31
The task is waiting for a pin change event, port H.
TaskWaitPinChangeJ0
32
The task is waiting for a pin change event, port J.
TaskWaitPinChangeJ1
33
The task is waiting for a pin change event, port J.
TaskWaitPinChangeK0
34
The task is waiting for a pin change event, port K.
TaskWaitPinChangeK1
35
The task is waiting for a pin change event, port K.
TaskWaitPinChangeQ0
36
The task is waiting for a pin change event, port Q.
 |
 |
 |
