Function returning UnsignedInteger

ShiftInEx(dataPin, clkPin, bitCnt, flags)

ShiftInEx(dataPin, clkPin, bitCnt, flags, bitTime)

The pin used to input data.

The pin used to output a clocking signal.

The number of bits to read in (1 to 16).

Flag bits controlling the operation.

The optional duration of each bit in ticks (see description).

This function can be used to input data from a synchronous serial device like a shift register. The pin

specified for input will be made an input but the pin specified for the clock signal must already be an

output and be at the desired initial logic level. The flags parameter controls how the shifting process is

performed as described in the table below.

Control Flag Definitions

Sample the input after the active clock edge

Sample the input before the active clock edge

Fastest possible bit time

Use the provided bitTime parameter

The active clock edge is the leading clock edge

The active clock edge is the trailing clock edge

The remaining bits are currently undefined but may be employed in the future.

For each of the number of bits specified, either the state of the data pin will be read and saved first or the

clock line will be changed to the opposite state first depending on bit 1 of the flags parameter. Finally,

the clock line will be returned to the original state thus completing one bit cycle.

If the flags parameter so specifies, the bitTime parameter value will be used to control the bit rate of

the shifting process. The units of the bitTime parameter are, by default, 1 CPU cycle (67.8ns at

14.7MHz). However, Register.TimerSpeed1 may be changed to adjust the controlling clock speed.

If the bitTime parameter is not provided or if the value given is zero, the shifting will occur at the

Due to processing overhead the minimum bit time in the controlled speed mode is approximately 60 CPU

cycles (4µS at 14.7MHz). Attempting faster bit times in the controlled speed mode will produce undefined

results. Without speed control, the bit time is approximately 37 CPU cycles (2.5µS at 14.7MHz). Note

that the duty cycle of the clock signal will be closer to 50% in the controlled speed mode. Without speed

control, the active clock phase can be as little as 20% of the period.

The returned value consists of the data bits read arranged in MSB or LSB order as specified by the

flags parameter. If MSB order is specified, the first bit read will be in the most significant bit position of

the result. If LSB order is specified, the first bit read will be in the least significant bit position. If fewer

than 16 bits are read, the remaining bits will be zero.
