ZBasic System Library
206
ZBasic Microcontrollers
Type
Subroutine
Invocation
OpenSPI(channel, flags, csPin)
OpenSPI(channel, flags, csPin, rxDelay)
Parameter
Method
Type
Description
channel
ByVal
Byte
The SPI channel to open (1-4).
flags
ByVal
integral
Flags controlling the SPI communication.
csPin
ByVal
Byte
The pin for the chip select signal to the device.
rxDelay
ByVal
Byte
The delay time prior to each received byte.
Discussion
This subroutine prepares an SPI channel for use as a master. By default, the hardware SPI controller is
used to implement the SPI protocol but on some devices, a bit-bang implementation can be enabled (see
DefineSPI).
Four channels are supported, numbered 1 through 4. It does not matter if the particular channel has
been previously opened. The flags parameter specifies the characteristics of the SPI communication
as shown in the table below. They must be set to be compatible with the device with which you want to
communicate. See the table below for details. The csPin parameter specifies the pin number that you
wish to control the device’s chip select input. The pin will be made an output and set to the inactive state
(as specified by bit 6 of the flags parameter). Any general purpose I/O pin of the device may be used
as the slave select pin. Note, however, that if the pin dedicated SS pin is not used to select remote
slaves, it must be configured as an output or remain at the logic high state for the duration of an SPI
operation. Also, for ZX devices that use an external SPI EEPROM for program storage (e.g. ZX-24, ZX-
24a), the SS pin is used to select the SPI EEPROM and therefore cannot be used for any other purpose.
The table below describes the function of the bits of the flags parameter. The shaded entries do not
apply to the software SPI implementation.
SPI Channel Control Bits
Function
Hex Value
Binary Value
Bit Rate f/4
&H00
xx xx xx 00
Bit Rate f/16
&H01
xx xx xx 01
Bit Rate f/64
&H02
xx xx xx 10
Bit Rate f/128
&H03
xx xx xx 11
Clock Phase False
&H00
xx xx x0 xx
Clock Phase True
&H04
xx xx x1 xx
Clock Low at Idle
&H00
xx xx 0x xx
Clock High at Idle
&H08
xx xx 1x xx
Use Hardware SPI
&H00
xx x0 xx xx
Use Software SPI
&H10
xx x1 xx xx
Bit Order – MSB first
&H00
xx 0x xx xx
Bit Order – LSB first
&H20
xx 1x xx xx
Active Low Chip Select
&H00
x0 xx xx xx
Active High Chip Select
&H40
x1 xx xx xx
Double Speed
&H80
1x xx xx xx
The remaining bits are currently undefined but they may be employed in the future. Because of this
possibility, the undefined flag bits should be zero. Bits 3 and 2 taken together specify the SPI mode 0-3,
e.g. xx xx 00 xx specifies mode 0. When using the hardware SPI controller, if the Double Speed bit is set,
the SPI channel will run at twice the frequency specified by the two low order flag bits. The value of f for
 |
 |
 |
