ZBasic Microcontrollers
The various ZBasic target devices offer a variety of resources for use in your program, e.g. timers,
interrupts, UART (hardware serial port), analog-to-digital converters, etc. Some of these resources are
allocated to specific functions of ZBasic and/or are used by certain ZBasic System Library routines. The
resources available on a particular target device vary and the remainder of this section documents the
availability for each supported device. Consult the datasheet for the particular target device for detailed
information about the device.
In some of the following sub-sections, resource usage is described separately for ZX devices and generic
target devices. In others, resource usage is described only in terms of the base device and it is thus
necessary to know the base device underlying your particular ZX device; the table below shows the
correspondence.
Base CPU Type for ZX Devices
ZX Device
Base CPU Type
ZX-24, ZX-40, ZX-44, ZX-24e
mega32
ZX-24a, ZX-40a, ZX-44a, ZX-24ae
mega644
ZX-24p, ZX-40p, ZX-44p, ZX-24n, ZX-40n, ZX-44n,
ZX-24ne, ZX-24pe, ZX-24nu, ZX-24pu
mega644P
ZX-24r, ZX-40r, ZX-44r, ZX-24s, ZX-40s, ZX-44s,
ZX-24t, ZX-40t, ZX-44t, ZX-24ru, ZX-24su
mega1284P
ZX-328n, ZX-328l, ZX-32n, ZX-32l, ZX-328nu
mega328P
ZX-1280, ZX-1280n
mega1280
ZX-1281, ZX-1281n, ZX-1281e, ZX-1281ne
mega1281
ZX-128e, ZX-128ne
mega128
ZX-128a1
xmega128A1
ZX-24u, ZX-128a4u
xmega128A4U
ZX-24x, ZX-32a4, ZX-24xu
xmega32A4
In the following sub-sections, some of the tables include package designation codes for the different
processor types because the pin assignments vary by package type. The table below gives package
designation codes and the corresponding package types for various devices. Note, particularly, that
suffixes like A, P and PA have been omitted because the package availability is generally the same
irrespective of the suffix.
Package Designation Codes
Code
Package Types
Device or Family
L44
PLCC-44
mega8515, mega8535
P14
PDIP-14, SOIC-14
tiny24, tiny44, tiny441, tiny84, tiny441, tiny841
P20
PDIP-20, SOIC-20
tiny2313, tiny4313
P28
PDIP-28
tiny48, tiny88, ATmega
P40
PDIP-40
ATmega
Q20
VQFN-20, QFN-20, MLF-20
tiny24, tiny44, tiny441, tiny84, tiny441, tiny841, tiny2313, tiny4313,
tiny1634
S20
TSSOP-20, SOIC-20
tiny87, tiny167, tiny1634
T28
TQFP-28, MLF-28, QFN-28
tiny48, tiny88, ATmega
T32
TQFP-32, MLF-32, QFN-32
tiny48, tiny88, tiny87, tiny167, tiny828, ATmega
T44
TQFP-44, MLF-44, QFN-44
various ATmega. ATxmega
T64
TQFP-64, MLF-64, QFN-64
various ATmega. ATxmega
T100
TQFP-100, MLF-100, QFN-100
various ATmega. ATxmega
 |
 |
 |
