ZBasic System Library
157
ZBasic Microcontrollers
Type
Function returning UnsignedLong
Invocation
GetTimeValue()
GetTimeValue(tick)
Parameter
Method
Type
Description
tick
ByVal
integral
The tick count to decompose.
Discussion
This function decomposes a tick count into the equivalent hour, minute, second and fractional second
components and packs them into a 32-bit value as shown below. If the tick count is omitted, the value of
Register.RTCTick is used.
Note that Register.RTCTick is initialized to zero on power-up or reset. This corresponds to 0:00:00.
Time Value Fields
Bits
Position
Mask
Description
31-27
&Hf8000000
Hour (0 to 23)
26-21
&H07e00000
Minute (0 to 59)
20-15
&H001f8000
Second (0 to 59)
14-0
&H00007fff
Fractional Second (0 to F_RTC_TICK-1)
The 'fractional second' field represents the accumulation of RTC ticks between each second. The floating
point equivalent of the seconds value represented by the converted time value can be calculated using
code like that shown in the example below.
Example
Dim time as UnsignedLong
Dim seconds as Single
' compute the equivalent full and fractional seconds value
time = GetTimeValue()
seconds = CSng(Shr(time, 15) And &H3f) + _
CSng(time And &H7fff) / CSng(Register.RTCTickFrequency)
Compatibility
The first form of the function is not available if the RTC is not enabled in your application. Neither form is
supported in BasicX compatibility mode or on VM mode ZX devices.
