DefineX10(channel, rxPin, txPin, flags)
DefineX10(channel, rxPin, txPin, flags, agcResetPin, agcWindowPin)
Parameter
Method
Type
Description
channel
ByVal
Byte
The X-10 channel being defined. The valid range is 1-2.
rxPin
ByVal
Byte
The pin which will serve as the receive line.
txPin
ByVal
Byte
The pin which will serve as the transmit line.
flags
ByVal
Byte
Configuration flags. See the discussion below.
agcResetPin
ByVal
Byte
The pin on which to generate the AGC reset signal.
agcWindowPin
ByVal
Byte
The pin on which to generate the AGC window signal.
Discussion
This routine configures an X-10 communication channel, preparing it to be opened using OpenX10(). If
the specified channel is already open, this routine does nothing. Likewise if the specified channel is
invalid or if both the rxPin and txPin parameters are zero or invalid. Note that either rxPin or txPin
may be zero, allowing you to define a transmit-only or a receive-only X-10 channel. If valid, the pins
specified by rxPin and txPin are automatically configured as input and output, respectively.
The flags parameter contains several bit fields used to specify some of the details of the operation of
the X-10 channel.
Configuration Flags Bit Values
Function
Hex Value
Bit Mask
50Hz mode (only used in 3-phase mode)
&H40
x1 xx xx xx
60Hz mode (only used in 3-phase mode)
&H00
x0 xx xx xx
Three phase mode
&H20
xx 1x xx xx
Single phase mode
&H00
xx 0x xx xx
Attempt to detect transmit/receive collisions
&H10
xx x1 xx xx
LSB-first Transmit Bit Order
&H08
xx xx 1x xx
MSB-first Transmit Bit Order
&H00
xx xx 0x xx
Inverted Transmit Logic
&H04
xx xx x1 xx
Non-inverted Transmit Logic
&H00
xx xx x0 xx
LSB-first Receive Bit Order
&H02
xx xx xx 1x
MSB-first Receive Bit Order
&H00
xx xx xx 0x
Inverted Receive Logic
&H01
xx xx xx x1
Non-inverted Receive Logic
&H00
xx xx xx x0
The remaining bits are currently undefined but may be employed in the future.
When non-inverted modes are selected, the idle state of the transmit line or receive line will be logic 0.
Whether you should choose the inverted or non-inverted mode depends on the interface circuitry that you
use to connect to your X-10 transmitter/receiver.
When LSB-first modes are selected, the first bit to be sent/received will be the least significant bit of each
byte. This is useful when a Bit array is used to assemble/decompose the data that is sent/received since
the lower-indexed bits in a byte are of lower significance.
The second form with the additional parameters is provided for use with the CM15A and similar modules.
The fifth parameter specifies a pin number on which to generate an active low signal to reset the CM15A
AGC circuitry. The sixth parameter specifies a pin number on which to generate an active high signal
 |
 |
 |
