Register.ExtRamConfig
This UnsignedInteger value indicates the current external RAM configuration. Of course, it is only
meaningful on ZBasic devices that support external RAM, e.g. the ZX-1281. Although you may change
this value during execution, the configuration of the external RAM interface will not be affected until the
next time the device resets (i.e. following power up, WatchDog reset, download, etc.).
Register.FirstTime
This read-only Boolean value is identical to that which would be returned by the FirstTime() function.
Note, however, that reading the value via Register.FirstTime does not reset the flag like invoking
the FirstTime() function does.
Register.UserSP
This UnsignedInteger register contains the value of the stack pointer for the current task at the
moment it is referenced. This value may be useful in estimating the stack usage for a task. For native
mode devices (e.g. the ZX-24n) the value of Register.UserSP is identical to Register.SP.
Caution: modifying this value will probably cause your program to malfunction.
Register.SP
This UnsignedInteger register contains the value of the hardware stack pointer of the underlying
processor at the moment it is referenced. For VM code devices, there are few, if any, practical uses for
this value. See, instead, Register.UserSP. For native mode devices, the value of Register.SP is identical
to Register.UserSP and indicates the value of the current task’s stack pointer at moment it is referenced.
Caution: modifying this value will probably cause your program to malfunction.
3.8 Built-in Constants
The compiler provides several built-in constants. These constants may be used in conditional directives
and they may also be used as if they were constants defined by the normal means. The entries in the
table below that begin with Option typically derive their value from the corresponding Option directives,
the corresponding compiler command line options or their respective default values.
Name
Type
Description
Module.Name
String
The name of the module being compiled.
Module.Number
UnsignedInteger The ordinal number of the module being compiled.
Option.AllocStr
Boolean
Indicates if dynamic string allocation is in effect.
Option.AtnChar
Byte
Gives the value of the ATN character (if non-zero).
Option.Base
Integer
Gives the array base value for the current module.
Option.CodeLimit
UnsignedLong
Specifies the code size limit (zero if none is specified).
Option.Com1Speed
Long
Deprecated. Use Option.ConsoleSpeed.
Option.ComChannels
Byte
Indicates the maximum number of SW UART channels.
Option.ConsoleChannel
Byte
Indicates the console serial channel (e.g. 1 means Com1).
Option.ConsolePin
Byte
Gives the pin to be used for console output (zero if none).
Option.ConsoleSpeed
Long
Gives the current default console channel baud rate.
Option.CPUFamily
String
Deprecated. Use Option.TargetFamily.
Option.CPUType
String
Deprecated. Use Option.TargetMCU.
Option.ExtRamAble
Boolean
Indicates if the device supports external RAM use.
Option.ExtRamEnabled
Boolean
Indicates if external RAM use is enabled.
Option.HeapLimit
UnsignedInteger Indicates the specified heap limit.
Option.HeapReserve
UnsignedInteger Indicates the default or specified minimum heap size.
 |
 |
 |
